BST-5800A plastic injection molding machine

BST-5800A plastic injection molding machine

BST-5800A shot weight:2230-2340g，Max Opening Stroke:760MM,Space Between Tie Bars:800X774MM
we have Imported advanced computer systems, Chinese / English interface.
You can save 100 sets of mold parameters.
Advanced clamping structure and injection parts, precision hydraulic system and circuit design.

machine size(LxWxH):

8.75x2.2x2.3m

Quantity:

Inquire Add To Basket

Share this:

Model：BST-5800A
origin：Zhang Jia Gang city
packaging：the tray

Product Description
Product Description1
Product Description2

BST-5800A injection molding machine
The computer is imported from Industry family,The LCD displaying screen with high clarity has Chinese and English language to display
CLAMPING UNIT;
New type 5-point toggle device with the advantage of stable movement curve and gentle shock
Hard chrome plated high tensile strength tie bars made of superior alloy with a good wear and corrosion resistance ability
Transducer control clamping stroke
INJECTION UNIT
Nitrided screw and barrel with long service life
Smelted screw with big L/D ratio to the result of high quality plasticizing and color-fixing
Transducer control injection stroke

MODEL	BST-5800A
INJECTION UNIT		A	B
Screw diameter	mm	84	86
Shot size(theoretical)	Cm³	2480	2600
Shot weight	g	2230	2340
Injection pressure	Mpa	152	145
Injection rate	g/s	482	506
Screw L/D ratio	L/D	20.6	20
Screw speed	r.p.m	0-150
Nozzle Diameter	Srmm	20
CLAMPING
Clamp tonnage	KN	5800
Toggle stroke	mm	760
Mould Thickness	mm	290-810
Space between tie-bars	mm	800-774
Ejector stroke	mm	200
Ejector tonnage	KN	125
Ejector number	Piece	13
Hole Diameter	mm	200
OTHERS
Heat power	KW	28.1
Max. pump pressure	MPa	16
Pump motor power	KW	18.5+30
Valve Size	mm	cartridge valve
Machine dimension	m	8.75X2.2X2.3
Machine weight	t	21.8
Oil tank capacity	L	850

Quality:12month Quality Guarantee,Free spare parts replacement,(Not include man-made sabotage)
Service:We provide free advanced training and maintance in china factory ,and 24hours on-line or phone service
If you request ,we also can provdie installaton and training abroad ,until customer’s satisfication
Delivery time:65-80days after advance payment
Payment:In cash ,T/T transfer ,LC etc
Goals:Chase customers’requirment ,and improve ourselves better
