BST-6500A plastic injection molding machine

BST-6500A plastic injection molding machine

BST-6500A shot weight :2745-2870g，MAX OPENING STROKE:880MM，SPACE BETWEEN TIE BARS:385X350MM，
we have Imported advanced computer systems, Chinese / English interface.
You can save 100 sets of mold parameters.
Advanced clamping structure and injection parts, precision hydraulic system and circuit design.

machine size(LxWxH):

9.3x2.2x2.4m

Quantity:

Inquire Add To Basket

Share this:

Model：BST-6500A
origin：Zhang Jia Gang city
packaging：the tray

Product Description
Product Description1
Product Description2

BST-6500A injection molding machine
The computer is imported from Industry family,The LCD displaying screen with high clarity has Chinese and English language to display
CLAMPING UNIT;
New type 5-point toggle device with the advantage of stable movement curve and gentle shock
Hard chrome plated high tensile strength tie bars made of superior alloy with a good wear and corrosion resistance ability
Transducer control clamping stroke
INJECTION UNIT
Nitrided screw and barrel with long service life
Smelted screw with big L/D ratio to the result of high quality plasticizing and color-fixing
Transducer control injection stroke
The machines have compact structure, reasonable design, high configuration, energy saving, suitable for producing different big weight, big size and hig precision products.

MODEL	BST-6500A
INJECTION UNIT		A	B
Screw diameter	mm	90	92
Shot size(theoretical)	Cm³	3050	3190
Shot weight	g	2745	2870
Injection pressure	Mpa	159	152
Injection rate	g/s	560	592
Screw L/D ratio	L/D	20	19.6
Screw speed	r.p.m	0-120
Nozzle Diameter	Srmm	20
CLAMPING
Clamp tonnage	KN	6500
Toggle stroke	mm	880
Mould Thickness	mm	350-860
Space between tie-bars	mm	860X819
Ejector stroke	mm	220
Ejector tonnage	KN	160
Ejector number	Piece	13
Hole Diameter	mm	200
OTHERS
Heat power	KW	37.1
Max. pump pressure	MPa	16
Pump motor power	KW	25+30
Valve Size	mm	cartridge valve
Machine dimension	m	9.2X2.2X2.4
Machine weight	t	26
Oil tank capacity	L	1000

Quality:12month Quality Guarantee,Free spare parts replacement,(Not include man-made sabotage)
Service:We provide free advanced training and maintance in china factory ,and 24hours on-line or phone service
If you request ,we also can provdie installaton and training abroad ,until customer’s satisfication
Delivery time:75-85days after advance payment
Payment:In cash ,T/T transfer ,LC etc
Goals:Chase customers’requirment ,and improve ourselves better
