BST-8500A plastic injection molding machine

BST-8500A plastic injection molding machine

BST-8500A型 Shot weight 4200-4350g，MAX.CLAMPING FORCE:980MM，SPACE BETWEEN TIE BARS :1016X980MM，we have Imported advanced computer systems, Chinese / English interface.
You can save 100 sets of mold parameters.
Advanced clamping structure and injection parts, precision hydraulic system and circuit design. 。

machine size(LxWxH):

11.0x2.4x2.75m

Quantity:

Inquire Add To Basket

Share this:

Model：BST-8500A
origin：Zhang Jia Gang city
packaging：the tray

Product Description
Product Description1
Product Description2

BST-8500A injection molding machine
The computer is imported from Industry family,The LCD displaying screen with high clarity has Chinese and English language to display
CLAMPING UNIT;
New type 5-point toggle device with the advantage of stable movement curve and gentle shock
Hard chrome plated high tensile strength tie bars made of superior alloy with a good wear and corrosion resistance ability
Transducer control clamping stroke
INJECTION UNIT
Nitrided screw and barrel with long service life
Smelted screw with big L/D ratio to the result of high quality plasticizing and color-fixing
Transducer control injection stroke
The machines have compact structure, reasonable design, high configuration, energy saving, suitable for producing different BIG weight, big size and hig precision products.

MODEL	BST-8500A
INJECTION UNIT		A	B
Screw diameter	mm	105	108
Shot size(theoretical)	Cm³	4670	4840
Shot weight	g	4200	4350
Injection pressure	Mpa	149	141
Injection rate	g/s	780	830
Screw L/D ratio	L/D	21	20.4
Screw speed	r.p.m	0-100
Nozzle Diameter	Srmm	25
CLAMPING
Clamp tonnage	KN	8500
Toggle stroke	mm	980
Mould Thickness	mm	400-980
Space between tie-bars	mm	1016X980
Ejector stroke	mm	260
Ejector tonnage	KN	186
Ejector number	Piece	21
Hole Diameter	mm	250
OTHERS
Heat power	KW	42.5
Max. pump pressure	MPa	16
Pump motor power	KW	37+37
Valve Size	mm	cartridge valve
Machine dimension	m	11X2.4X2.75
Machine weight	t	45
Oil tank capacity	L	1300

Quality:12month Quality Guarantee,Free spare parts replacement,(Not include man-made sabotage)
Service:We provide free advanced training and maintance in china factory ,and 24hours on-line or phone service
If you request ,we also can provdie installaton and training abroad ,until customer’s satisfication
Delivery time:75-80days after advance payment
Payment:In cash ,T/T transfer ,LC etc
Goals:Chase customers’requirment ,and improve ourselves better
